Size: 15*10*7.5mm
plunger:φ2.6mm
Voltage: DC3.3V
Stroke: 2mm
Force: Can move
Power : 1.37W
Current: 0.41A
Resistance: 10Ω
Life: ≥200,000 times
Working cycle: 3s on, 3s off
Size: 15.5*10.8*8mm
plunger:φ4mm
Voltage: DC3V
Stroke: 3mm
Power : 2.57W
Current: 0.85A
Resistance: 3.5Ω
Life: ≥300,000 times
Working cycle: 0.2s on, 1s off
Size: 20.5*12*11mm
Voltage: DC12V
Stroke: 0-5mm
Force: 0.2-2N
Power : 13W
Current: 1.09A
Resistance: 11Ω
Life: ≥1000,000 times
Working cycle: 0.5s on, 2s off
Size: 25*12*10mm
Voltage: DC24V
Force: 0.8-2N
Power : 14.4W
Current: 0.6A
Resistance: 40Ω
Working cycle: 0.1s on, 1s off
Size: 20*16*13mm
plunger:φ5mm
Stroke: 0-4mm
Force: 0.8-3.5N
Power : 9W
Current: 0.75A
Resistance: 16Ω
Working Cycle: 0.5s On, 1.5s Off
Size: 25.5 *15*13mm
Voltage: DC5V
Stroke: 0-6mm
Force: 0.3-3N
Power : 4.16W
Current: 0.83A
Resistance: 6Ω
Working Cycle: 5s On, 10s Off
Size: 30 *15*10mm
Plunger: φ5mm
Power: 6.86W
Current: 0.57A
Resistance: 21Ω
Working Cycle: 0.55s On, 0.5s Off
Size: 37*14*10mm
Plunger: φ4.4mm
Force: 0.8-3N
Power: 25.3W
Current: 2.1A
Resistance: 5.7Ω
Working Cycle: 0.2s On, 10s Off
Size: 15.5 *22*19mm
Plunger: φ6.1mm
Force: 0.5-3N
Power: 6.25W
Current: 1.25A
Resistance: 4Ω
Working Cycle: Continuous Power (High Voltage Start Low Voltage Hold)
Size: 22*18*14mm
Plunger: φ6mm
Force: 0.15-2N
Power: 8W
Current: 0.67A
Resistance: 18Ω
Working Cycle: 0.5s On, 1s Off
Size: 25*20*16mm
Force: 1-3N
Power: 5.3W
Current: 0.66A
Resistance: 12Ω
Working Cycle: 1s On, 1s Off
Size: 26.8*18*14mm
Voltage: AC220V
Force: 2-8N
Power: 80W
Current: 0.4A
Resistance: 220Ω
Working Cycle: 0.1s On, 30s Off
